2P 10KA MCB

As a professional manufacturer and supplier in China, XENHO would like to provide you durable 2P 10KA MCB, which is a high-performance circuit breaker designed for safe power distribution. This high-performance circuit breaker is specifically engineered for safe power distribution; it features a double-pole design, adheres to the IEC 60898-1 standard, and has obtained CE, CB, and CCC certifications. It is suitable for residential, commercial, and light industrial applications with high durability and stable performance.

What is 2P 10KA MCB?

The 2P 10KA MCB is a compact protective device designed to automatically disconnect circuits under overload or short-circuit conditions. It ensures uninterrupted safety for electrical systems while maintaining stable performance across diverse applications.

Product Applications

2P 10KA MCB is suitable for residential distribution boxes, lighting circuits, socket circuits, air conditioner lines, commercial lighting, office sockets, light industrial equipment, pumps, fans, as well as new energy PV AC side and charging piles.

Protection Functions

Overload protection: bimetal strip provides time-delayed trip when current exceeds rating.

Short-circuit protection: electromagnetic coil opens circuit within 0.01 seconds. Isolation function: contact gap meets safety requirements in open position.

Key Features

High breaking capacity: 10kA for strong fault interruption

Rated current range: 6A–63A optional

Tripping curves: B / C / D type selectable

Durable housing: UL94 V-0 flame-retardant PA66 material

Conductive system: high-purity copper or silver-plated alloy

Long service life: 20,000 mechanical cycles & 10,000 electrical cycles

Component Material

Housing: The housing of 2P 10KA MCB is made of UL94 V-0 flame retardant PA66.

Internal conductive parts: Internal conductive parts are high-purity copper or silver-plated copper alloy.

Bi-metal strip: Bi-metal strip is nickel-chromium alloy, and the arc chamber consists of galvanized steel plates. 2 poles, rated current 6A-63A optional, tripping characteristics B/C/D optional, mechanical life 20,000 cycles, electrical life 10,000 cycles, compliant with IEC 60898-1, certified with CE, CB and CCC.

Important Notes & Installation Method:

Standard 35mm DIN rail mounting: hook upper slot onto rail and press down to lock. Each terminal accommodates 1-2 wires, strip length 8-10mm.

Selection: ensure rated current exceeds load current and breaking capacity exceeds prospective short-circuit current.

Installation: work on de-energized circuits only, do not reverse line and neutral, input on top and output on bottom.

After tripping, clear fault before resetting, do not forcibly close, keep distribution box dry and clean. XENHO offers 24-month warranty and OEM/ODM customization services.
